AquaSTAR series R290 heat pump water heater developed by Amitime is a epitome of innovation in home comfort technology. This is an integrated all-in-one heat pump water heater series from Amitime, that champions eco-friendly application with its R290 refrigerant. Its smart operation panel provides an intuitive interface for flexible functions, and with built-in DTU & WIFI, it becomes a natural extension of your smart home network. The working principle makes it easy to combine with residential fresh air system.
AquaSTAR R290 heat pump water heater represents the forefront of sustainable, intelligent, and efficient water heating, promising a greener lifestyle. Contact Amitime heat pump supplier to figure out how it can benefit your business further!
R290 Refrigerant: Using eco-friendly R290 refrigerant to achieve carbon neutrality and reduce the impact of global warming, AquaSTAR is an efficient series of Amitime heat pump water heaters. The maximum outlet water temperature can reach 75℃.
Smart operation panel: The clear Ul design is user-friendly and allows setting water temperature, running mode, timer, etc. freely. With processed cover, the operation panel is anti-UV and durable.
Flexible control solutions: The inbuilt DTU & WIFI module makes remote APP control possible and convenient. Besides, the SG-ready function provides a cost-effective control with the power grid in peak and valley time.
Micro-Channel: Micro-channel design, winding technology on the outside of the inner tank, the channel does not contact with the water in the tank, no corrosion, scaling, leakage and other conditions. With flexible laminating process, the heat exchange area is larger. Water tank adopts natural circulation system, high efficiency and energy saving.
DC centrifugal fan: Maximizing gas flow and minimizing energy loss to achieve good ventilation. You could set periodic air exchange to use with the fresh air system for a smart home.
| PARAMETER | ||||
| Model | / | QAFF-01HGAAB/200GX | QAFF-01HGAAB/250GX | QAFF-01HGAAB/300GX |
| Air outlet method | Top | Top | Top | |
| Volume | L | 200 | 250 | 300 |
| Rated Heating Capacity | kW | 1.28 | 1.28 | 1.28 |
| Power Supply | V/Hz/P | 230/50/1 | 230/50/1 | 230/50/1 |
| COP(EN16147)7/6℃ | W/W | 2.61 | 3.11 | 3.08 |
| Heating Time* | h | 5.41 | 6.8 | 8.15 |
| Refrigerant | / | R290(150g) | R290(150g) | R290(150g) |
| Electric Heater | kW | 2 | 2 | 2 |
| Noise | dB(A) | 42 | 42 | 42 |
| Operation Range | ℃ | -5～43 | -5～43 | -5～43 |
| Water Outlet Temp Range | ℃ | 38～60 | 38～60 | 38～60 |
| Max. Water Outlet Temp | ℃ | 75 | 75 | 75 |
| Net Weight | kg | 95 | 105 | 115 |
| Net Dimension | mm | ∮640*1764 | ∮640*1890 | ∮640*2016 |
| *Testing condition is ambient temp DB/WB 7℃/6℃, water inlet/outlet is 15℃/55℃; | ||||
| PARAMETER | ||||
| Model | / | QAFF-03HGAAC/200GX | QAFF-03HGAAC/250GX | QAFF-03HGAAC/300GX |
| Air outlet method | Side | Side | Side | |
| Volume | L | 200 | 250 | 300 |
| Rated Heating Capacity | kW | 3.5 | 3.5 | 3.5 |
| Power Supply | V/Hz/P | 230/50/1 | 230/50/1 | 230/50/1 |
| COP（20/15℃） | W/W | 4.81 | 4.92 | 4.95 |
| Heating Time* | h | 3.05 | 3.75 | 4.5 |
| Refrigerant | / | R290(450g) | R290(450g) | R290(450g) |
| Electric Heater | kW | 2 | 2 | 2 |
| Noise | dB(A) | 50 | 50 | 50 |
| Operation Range | ℃ | -5～43 | -5～43 | -5～43 |
| Water Outlet Temp Range | ℃ | 38～60 | 38～60 | 38～60 |
| Max. Water Outlet Temp | ℃ | 75 | 75 | 75 |
| Net Weight | kg | 100 | 110 | 125 |
| Net Dimension | mm | ∮640*1774 | ∮640*1900 | ∮640*2026 |
| *Testing condition is ambient temp DB/WB 20℃/15℃, water inlet/outlet is 15℃/55℃; | ||||
